Electromagnetic Door Lock 280 Kg

The Electromagnetic Door Lock is a high-performance locking solution designed to offer maximum security and convenience. With a robust holding force of 280kg (600lbs), it is ideal for controlling access in both residential and commercial properties in Abu Dhabi. This fail-safe lock ensures that in the event of a power failure, the door remains open, facilitating quick exits in emergencies.

Key Features:

• LED Sensor & Door Sensor: The lock is equipped with built-in LED and door sensors, making it an efficient and smart choice for controlling entry to your premises. The LED lights indicate the lock’s status, providing real-time feedback on the system’s operation.

• Voltage Compatibility: This lock operates on DC12V or DC24V, making it adaptable to different power configurations. It draws a current of 12V/500mA and 24V/250mA, ensuring low energy consumption without compromising on performance.

• High Holding Force: With an impressive 280kg (600lbs) holding force, the lock provides secure and reliable access control, making it suitable for doors that require a stronger, more dependable security solution.

• Weather and Temperature Resistant: Designed to withstand a wide range of environmental conditions, it operates efficiently within temperatures ranging from -10°C to 55°C and can tolerate humidity levels up to 90%.

Specifications:

• Lock Size: 250L x 48.5W x 25H (mm)

• Plate Size: 180L x 38W x 11H (mm)

• Weight: 2kg

• Material Finishes: Anodized aluminum for the shell, zinc for the magnetic components and armature plate

• Signal Output: Dry contact with a maximum current rating of 3A

Whether you’re securing a commercial building or a residential property in Abu Dhabi, this magnetic door lock ensures both safety and ease of use, providing an advanced access control system you can rely on.
